Acura 2008 MDX User Manual

CONTINUED
Remove the socket by turning it
one-quarter turn counterclockwise.
Pull the bulb straight out of its
socket.
Push the new bulb straight into
the socket until it bottoms.
Turn on the lights to make sure
the new bulb is working.
Put the socket back into the light
assembly, and turn it clockwise to
lock it in place.
Install the rear light assembly in
the rear pillar. Tighten the two
bolts. Snap the bolt covers into
position.
Open the tailgate. Place a cloth on
the edge of the light assembly
cover. Remove the cover by
carefully prying in the notch on its
middle edge with a flat-tip
screwdriver.
1.
4.
5.
6.
7.
8.
9.
Lights
Replacing a Back-up Light Bulb
Maintenance
407
COVER
BULB SOCKET
０７／０７／０９ １０：１７：３７ ３１ＳＴＸ６１０ ０４１２
