Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb from the fog
light assembly by turning it one-
quarter turn counterclockwise.
Remove the two bolts, and remove
the rear light assembly from the
rear pillar.
Open the tailgate. Use a flat-tip
screwdriver protected with a cloth
to pry open the two covers.
Determine which of the two bulbs
is burned out: turn signal/hazard
lights or side marker light.
1. 2.
3.
3.
4.
Lights
Replacing Rear Bulbs
(in Rear Pillar)
406
CONNECTOR
INNER FENDER
COVER
BOLT
BOLT
