Acura 2008 RL User Manual

Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the fog lights to test the
new bulb.
Reinstall the two undercover bolts
onthesideundercoverand
tighten them securely. Put the
holding clip back on the side
under cover and push on the
center until it locks (the center is
flushwiththehead).
Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb by turning it one-
quarter turn counterclockwise.
Carefully push up the side under
cover into the bumper.
Use a Phillips-head screwdriver to
remove the two undercover bolts,
and remove the holding clip with a
flat-tipped screwdriver.
3.
4.
5.
6.
8.
7.
1.
2.
Lights
Maintenance
413
CLIP
CONNECTOR
BULB
BOLTS
０７／０５／１７ ０９：５１：３７ ３１ＳＪＡ６３０ ０４１８

Acura 2008 RL Specifications

General

Brand	Acura
Model	2008 RL
Category	Automobile
Language	English
