Determine which of the two bulbs
is burned out: turn signal or back-
up light.
Remove the socket by turning it
one-quarter turn counterclockwise.
Remove the burned out bulb by
pulling it straight out of its socket.
Open the trunk lid, and remove
the left or right maintenance lid.
Remove the mounting nut with an
8mmwrench.
Carefully pry in the top or bottom
edge of the trim with a small flat-
tipped screwdriver, and pull the
trim straight back.
Remove the two mounting bolts
with an 8 mm wrench.
Pull the taillight assembly straight
back out of the body.
2.
1. 3.
4.
5.
6.
7.
8.
Lights
Replacing Rear Bulbs
414
MOUNTING NUT
MAINTENANCE LID
BOLTS
BULBS
TAIL LIGHT TRIM
SOCKETS
０７／０５／１７ ０９：５１：５０ ３１ＳＪＡ６３０ ０４１９
