No. Amps. No. Amps.Circuits Protected Circuits Protected
1
2
3
4
5
30 A
30 A
30 A
30 A
20 A
6
7
8
9
20 A
7.5 A
30 A
7.5 A
SH-AWD
Premium amplifier
Passenger’s power window
Driver’s automatic seat belt
tensioner/e-pretensioner
Right rear power window
Heated seats
Illumination lights
Passenger’s automatic seat
belt tensioner/
e-pretensioner
Air conditioner
Fuse Locations
520
INTERIOR FUSE BOX
