6 of 25 BII 48865 (1303) © 2013 American Honda Motor Co., Inc. – All Rights Reserved.
11. Pull away the driver’s door opening seal from around
the driver’s dashboard side cover.
12. Remove the driver’s dashboard side cover (two
clips, three retaining tabs, and three hooks).
13. Release the driver’s front door sill trim (five clips and
two retaining tabs).
2 CLIPS
DRIVER’S DASHBOARD
SIDE COVER
DRIVER’S DOOR
OPENING SEAL
(Pull away.)
3 RETAINING
TABS
3 HOOKS
3 CLIPS
Raise.
FRONT
DRIVER’S FRONT
DOOR SILL TRIM
2 RETAINING
TABS
2 CLIPS
14. Pull away the door opening seal, and remove the
driver’s kick panel (two clips).
15. Reconnect the negative cable to the battery. Press
the engine start/stop button to select the ON mode.
Lower the tilt lever, and release the column band
(two clips).
2 CLIPS
DRIVER’S
KICK PANEL
DOOR OPENING
SEAL
(Pull away.)
STEERING
WHEEL
STEERING
WHEEL
UPPER COLUMN
COVER
COLUMN
BAND
2 CLIPS
To Next Page
