Acura 2015 TLX Quick Reference Guide

449
uuReplacing Light BulbsuFront Turn Signal Light Bulbs
Maintenance
4. Push the tab to remove the coupler.
5. Turn the socket to the left and remove it.
6. Remove the old bulb and insert a new bulb.
1Front Turn Signal Light Bulbs
Insert a flat-tip screwdriver, lift and remove the
central pin to remove the clip.
Insert the clip with the central pin raised, and push
until it is flat.
Holding clip (B-type)
Central pin
Push until the
pin is flat.
Tab
Coupler
Bulb
Socket
15 ACURA TLX-31TZ36000.book 449 ページ ２０１４年９月２日 火曜日 午後５時２２分
