Turn on the headlights to test the
new bulb.
Insert the new bulb into the hole
and turn it one-quarter turn clock-
wise to lock it in place.
Put the light assembly into the
bumper. Tighten the mounting
bolt.
Remove the socket by turning it
one-quarter turn counterclockwise.
Open the tailgate. Use a
screwdriver protected with a cloth
to pry open the two covers.
Determine which of the four bulbs
is burned out: stop/taillight, turn
signal/hazard lights, side marker
light, or back-up light.
Remove the two screws and
remove the rear light assembly
from the rear pillar.
Remove the burned out bulb. To
remove the stop/taillight, back-up
or side marker light bulb, pull the
bulb straight out of its socket. To
remove the turn signal/hazard
light bulb, push it in and turn it
counterclockwise until it unlocks.
1.
2.
3.
4.
8.
6.
7.
5.
Replacing Rear Bulbs
Lights
Maintenance
298
