Testing of Readiness Codes
Your vehicle has “Readiness Codes” as part of the onboard self-diagnostic system.
Some states refer to these codes as a test to see if your vehicle’s emissions
components are working properly. The codes may not be read if you go through the
emissions testing just after the battery has gone dead or been disconnected.
To check if they are set, set the power mode to ON without starting the engine.
The malfunction indicator lamp will come on for several seconds. If it goes off, the
readiness codes are set. If it blinks five times, the readiness codes are not set.
If you are required to have your vehicle emissions tested before the readiness codes
are set, prepare the vehicle for retesting by doing the following:
1. Fill the gas tank to approximately 3/4 full.
2. Park the vehicle and leave the engine off for 6 hours or more.
3. Make sure the ambient temperature is between 40°F and 95°F (4°C and 35°C).
4. Start the engine without touching the accelerator pedal, and let it idle for 20
seconds.
5. Keep the vehicle in Park (P). Increase the engine speed to 2,000 rpm, and hold it
there for about 3 minutes.
6. Let the engine idle with your foot off the accelerator for 20 seconds.
7. Select a nearby, lightly traveled major highway where you can maintain a speed
of 50 to 60 mph (80 to 97 km/h) for at least 20 minutes. Drive on the highway
with the vehicle in Drive. Do not use cruise control. When traffic allows, drive
for 90 seconds without using the accelerator pedal. (Vehicle speed may vary
slightly; this is OK.) If you cannot do this for a continuous 90 seconds because of
traffic conditions, drive for at least 30 seconds, then repeat two more times (for
a total of 90 seconds).
8. Drive in city/suburban traffic for at least 10 minutes. When traffic conditions
allow, let the vehicle coast for several seconds without using the accelerator
pedal or the brake pedal.
9. Park the vehicle and leave the engine off for 30 minutes.
The readiness codes are erased when the battery is disconnected, and set again
only after several days of driving under a variety of conditions.
If an emissions testing facility determines that the readiness codes are not set, you
may be requested to return at a later date to complete the test, or see your dealer.
Vehicle
*1: 2WD models
*2: AWD models
Model Acura MDX
No. of Passengers:
2tnorF
Rear 2nd Row 3
3rd Row 2
7latoT
Weights:
Gross Vehicle
Weight Rating
U.S.: 5,368 lbs (2,435 kg )
*1
5,677 lbs (2,575 kg )
*2
Canada: 2,575 kg
Gross Axle Weight
Rating (Front)
U.S.: 2,811 lbs (1,275 kg )
*1
2,910 lbs (1,320 kg )
*2
Canada: 1,320 kg
Gross Axle Weight
Rating (Rear)
U.S.: 2,734 lbs (1,240 kg )
*1
2,965 lbs (1,345 kg )
*2
Canada: 1,345 kg
Gross Combined
Weight Rating
U.S.:8,036 lbs (3,645 kg )
*1
9,833 lbs (4,460 kg )
*2
Canada: 4,460 kg
Air Conditioning:
Refrigerant Type HFC-134a (R-134a)
Charge Quantity 23.8 – 25.6 oz (675 – 725 g)
Lubricant Type PAG RL897
Fluids
Engine Oil
Engine Coolant
Recommended
·Genuine Acura Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil
Capacity
Change 5.4 US qt (5.1 )
Change
including
filter
5.7 US qt (5.4 )
Specified
Acura Long Life Antifreeze/Coolant Type 2
Ratio 50/50 with distilled water
Capacity
1.93 US gal (7.3 )
(change including the remaining 0.19 US gal
(0.72 ) in the reserve tank)
Washer Fluid
Tank Capacity
U.S.: 4 US qt (3.8 )
Canada: 5.6 US qt (5.3 )
Brake Fluid
Specified Acura Heavy Duty Brake Fluid DOT 3
Automatic Transmission Flui
d
Rear Differential Flui
d
*
Transfer Assembly Flui
d
*
Specified
Acura Automatic Transmission Fluid ATF-TYPE 3.0
Capacity Change 3.5 US qt (3.3 )
Specified Acura DPSF-II
Capacity Change 1.92 US qt (1.82 )
Specified
·Acura Hypoid Gear Oil HGO-1
·Hypoid gear oil SAE 75W-85 or SAE 90
(API grade GL4 or GL5)
Capacity Change0.45 US qt (0.43 )
SPECIFICATIONS
Tires
*1:Model with 18 inch wheel
*2: Model with 19 inch wheel
Regular
Size
245/60R18 105H
*1
245/55R19 103H
*2
Pressure
psi (kPa [kgf/cm
2
])
35 (240 [2.4])
Compact
Spare
*
Size
T165/80D17 104M
Pressure
psi (kPa [kgf/cm
2
])
60 (420 [4.2])
Wheel Size
Regular
18 x 8J
*1
19 x 8J
*2
Compact Spare
*
17 x 4T
Engine and Fuel
Engine
Fuel
Displacement 211.8 cu-in (3,471 cm
3
)
Spark PlugsNGK DILZKR7B11G
Type
Unleaded premium gasoline, Pump octane
number of 91 or higher
Fuel Tank Capacity 19.5 US gal (73.8 )
Light Bulbs
Headlights (High/Low Beam) LED
Fog Lights
*
LED
Front Turn Signal/Side Marker/
Parking Lights
28/8 W (Amber)
Daytime Running Lights LED
Side Turn Signal Lights (on Door
Mirrors)
LED
Brake Lights 21 W
Rear Side Marker Lights LED
DELsthgilliaT
Back-Up Lights 21 W
Rear Turn Signal Lights 21 W
High-Mount Brake Light LED
Rear License Plate LightLED
Puddle Lights
*
LED
Interior Lights
Front, Second Row and Third
Row Lights
LED
Front and Rear Ambient Lights LED
Vanity Mirror Lights 1.4 W
Door Courtesy Lights3.4 W
Door Inner Handle Lights LED
Console Compartment Light1.4 W
Glove Box Light 1.4 W
Foot Lights 5 W
Cargo Area Lights 5 W
*if equipped
