uuFusesuCircuit Protected and Amps for Each Fuse
Handling the Unexpected
Circuit Protected and Amps for Each Fuse
The current rating in brackets indicate that
you may find a fuse in the location even if
your particular model is not equipped with
the device the fuse is used for.
■
Engine Compartment
Circuit Protected Amps
1
Battery
100 A
*1
120 A
*2
Passenger’s Side Fuse Box 40 A
2
EPS 70 A
Passenger’s Side Fuse Box (40 A)
ABS/VSA FSR 30 A
−−
ABS/VSA Motor 30 A
−−
3
IG 50 A
Driver’s Side Fuse Box (40 A)
Passenger’s Side Light Main 30 A
Driver’s Side Fuse Box (60 A)
Driver’s Side Light Main 30 A
Main Fan Motor 30 A
−
*1
−
Wiper Motor
*2
30 A
Wiper Motor
*1
30 A
Sub Fan Motor
*2
*1:4-cylinder models
*2:6-cylinder models
4 Rear Defogger 40 A
5
Sub Fan Motor
*1
20 A
−
*2
−
6− −
7 − −
8 Heater Motor 40 A
9 Hazard 15 A
10 Horn 10 A
11 − −
12 Stop 15 A
13 IG Coil 15 A
14 FI Sub 15 A
15 Backup 10 A
16 Interior Lights 7.5 A
17 FI Main 15 A
18 DBW 15 A
19
−
*1
−
Back Up FI ECU
*2
7.5A
20 MG Clutch 7.5 A
21
Engine Oil Level
*1
7.5 A
Fan RLY
*2
Circuit Protected Amps
■
Driver Side
Circuit Protected Amps
1 − −
2 Seat Memory (7.5 A)
3 Washer 15 A
4 Wiper 10 A
5 Meter 7.5 A
6 ABS/VSA 7.5 A
7 ACG 15 A
8
STS
*1
(7.5 A)
Starter DIAG
*2
9 Fuel Pump 20 A
10 VB SOL
*
(10 A)
11 SRS 10 A
12 ODS 7.5 A
13
−
*1
(7.5 A)
STS
*2
14 − −
15 Daytime Running Lights 7.5 A
16 A/C 7.5 A
17 Accessory, Key, Lock 7.5 A
* Not available on all models
