297
uuFusesuCircuit Protected and Amps for Each Fuse
Handling the Unexpected
*1:4-cylinder models
*2:6-cylinder models
18 Accessory 7.5 A
19 Driver’s Power Seat Sliding (20 A)
20 Moonroof (20 A)
21
Driver’s Power Seat
Reclining
(20 A)
22
Rear Driver’s Side Power
Window
20 A
23
Front Accessory Power
Socket
20 A
24 Driver’s Power Window 20 A
25 Driver’s Side Door Lock 15 A
26 Left Front Fog Light (10 A)
27
Left Side Small Lights
(Exterior)
10 A
28 Left Headlight High Beam 10 A
29 TPMS 10 A
30 Left Headlight Low Beam 15 A
31 − −
32 Engine Oil Level
*
(7.5 A)
Circuit Protected Amps
■
Passenger Side
Circuit Protected Amps
1 Right Headlight High Beam 10 A
2
Right Side Small Lights
(Exterior)
10 A
3 Right Front Fog Light (10 A)
4 Right Headlight Low Beam 15 A
5 − −
6 Interior Lights 7.5 A
7 − −
8
Passenger’s Side Power Seat
Reclining
20 A
9
Passenger’s Side Power Seat
Sliding
20 A
10 Right Side Door Lock 10 A
11
Rear Passenger’s Side Power
Window
20 A
12
Console Accessory Power
Socket
20 A
13
Front Passenger’s Power
Window
20 A
14 − −
15 Premium AMP (20 A)
16 − −
17 − −
18 − −
19 Seat Heater 20 A
20 − −
21 − −
22 − −
Circuit Protected Amps
* Not available on all models
