662Y0500 • B
INSTALLATION
SPECIFICATION
Single-step switch with preheating and pre-purge, approved for
intermittent operation in cast iron and steel boilers.
Burner components:
• Spiral housing (injection-molded)
• Burner pipe (high-temperature resistant steel)
• Sound-proofed combustion system with thermodynamic fuel-air
mixing
• Electric motor with operating capacitor
• Oil pump with built-in solenoid valve
• Automatic oil firing unit for intermittent operation
• Flame monitoring
• Ignition transformer
• Ignition electrodes
• Nozzle assembly
• Oil preheater with release thermostat and drip stop
• Cover
• Connection plug
• Oil hoses with swivel nut
• Clamping flange
• Burner gasket and connection screws
The burner is heat-tested.
The combustion quality is guaranteed by certified test
certificates.
The burner is inserted into the boiler through the sliding flange
