Cinema Reference “Out Of The Box” Setup Chart
INPUT LABEL
COMPONENT
AUDIO INPUT
(R&L STEREO
- RCA TYPE)
DIGITAL
AUDIO INPUT
(COAX - RCA
TYPE)
DIGITAL
AUDIO INPUT
(OPTICAL -
TOS-LINK
TYPE)
RF
DEMODULATO
R INPUT
(LASER DISC -
RCA TYPE)
VIDEO INPUT
(COMPOSITE -
RCA TYPE)
S-VIDEO
INPUT (SUPER
VIDEO)
COMPONENT
VIDEO INPUT
(3 X RCA
TYPE)
LASER/DVD 1
AC-3 LASER DISC OR
COMBINATION PLAYER
-1-111-
LASERDISC 2
OLDER LASER DISC OR
SECOND LASER DISC
2--22--
DVD PLAYER 3
DVD PLAYER - 3 - - 3 3 1
VCR 4
VCR 4 - - - 4 4 -
DSS/SAT 5
DSS OR SATELLITE
RECEIVER
5---52-
CABLE/TV 6
CABLE BOX OR TV TUNER 6 - - - 6 - -
CD PLAYER 7
CD PLAYER 7 - - - 7 - -
TUNER 8
RADIO TUNER 8 ------
CASSETTE 9
CASSETTE DECK 1 ------
AUXILIARY 10
ANY DEVICE YOU WANT 3 - - - 8 - -
CAMCORDER 11
CAMCORDER 3 - - - 8 - -
VIDEOGAME 12
VIDEO GAME 3 - - - 8 - -
COMPUTER 13
COMPUTER INPUT 3 - - - 8 - -
PREAMP 14
AUDIO OR AUDIO/VIDEO
PREAMPLIFIER
3---8--
MULTIROOM 15
MULTI-ROOM AUDIO OR
AUDIO/VIDEO SYSTEM
3---8--
Please note, that Input Labels numbers
10-15 share the same "Out Of The Box"
audio and video inputs. Thus you can
connect only one of these devices to the
Cinema Reference. In the event that you
are not using other inputs or have
connected a CD player or DSS receiver
to a digital input, you can add more
devices to your system.
