In order to play an AC-3 Laser Disc,
you must connect the Digital AC-3
Output to a Digital Audio Input.
Laser Disc or Combination Laser/DVD Player
PCM/AC-3
Digital Out
Video
Out
RF • AC-3
Out (LD)
S-Video
Output
Optional S-Video Cable
(Only functional if you connect your TV or Projector
to the Cinema Reference's "Main" S-Video Output.)
Laser Disc AC-3 Loop Cable
(You must connect this cable to play
Dolby Digital (AC-3) Laser Discs.)
AC-3 RF Cable
(Only connect this cable if
laser disc can play AC-3.)
Video
Cable
Digital Output
(This cable carries Dolby Digital (AC-3) 6 channel audio from DVDs,
standard 2 channel digital audio from CDs & Laser Discs, as well
as DTS digital 6 channel audio.)
1
1
1
4
1
Changing the Cinema Reference’s Audio Input
If you are using a combi-player which only has an optical digital PCM/AC-3 output, you will need to use
an optical TOS-Link type cable to connect the combi-player to Optical #1 on the Cinema Reference.
Then follow these steps.
1 Turn the Input knob to LASER/DVD 1 and press the knob.
2 Turn the Mode knob clockwise to SETUP MODE and press the knob.
3 Turn the Mode knob to AUDIO INPUT and press the knob. Once the knob is pressed the will
read “DIGITAL IN 1”.
4 Turn the mode knob until the display reads OPTICAL IN 1 and press the knob.
You have now altered the LASER/DVD input to access Optical Input 1.
Connection 1
Connection 2
Connection 5Connection 4
Connection 3
To Next Page
