11
AX Manual / english
5.1 Controls
On the rear side you will find controls that allow de-
tailed fine-tuning of your loudspeakers to your particu-
lar room acoustics and personal listening preferences.
The following tips are intended to assist you at using
the controls in the best manner.
Please note that using the controls may have a great
impact on the overall sound characteristics of your
loudspeakers. We recommend using the controls with
utmost care and only after several audio tests with fa-
miliar recordings.
5.2 Tweeter Level
The ‘Tweeter Level’ works within the frequency
range of the tweeter raising or lowering up to ±4
dB. It alters this frequency range as a whole (see
fig.).
A5X/A7X/A77X/A8X only:
5.3 High / Low Shelf EQ (Room EQs)
The other two controls operate in a different man-
ner. The ‘High Shelf’ and the ‘Low Shelf’ are shelv-
ing filters, which progressively raise or lower up
to ±6 dB.
That means the shelving filters do not alter a whole
frequency band but alter in this band: from a cer-
tain point (5kHz respectively 300Hz in this case)
the frequencies are gradually being changed (see
fig.).
5. Speaker Adjustment
TWEETER LEVEL
