Adam A8X User Manual

15
English
11. Technical Data
A8X. Active Nearfield Monitor
Tweeter X-ART Tweeter
Velocity transfer ratio 4:1
Equivalent diaphragm ø 56 mm
/ 2“
Woofer 220 mm / 8.5“
Woofer material Carbon/Rohacell/Glass fiber
Built-in amplifiers 2
Woofer channel
1/2
150 W / 225 W
Tweeter channel
1/2
50 W / 75 W
Control Panel
Input Sensitivity -∞ to +14 dB
Tweeter gain ± 4 dB
High shelf > 5 kHz ± 6 dB
Low shelf < 300 Hz ± 6 dB
General Data
Frequency response 38 Hz - 50 kHz
THD 90dB/1m >100Hz ≤ 0,5%
SPL with sine wave 100 Hz to 3 kHz in 1m ≥ 112 dB
Max. peak acoustic output in 1m per pair ≥ 120 dB
Crossover frequency 2.300 Hz
Input XLR / RCA
Input impedance 30 kΩ
Weight 13 kg / 28.7 lb.
Magnetically shielded no
Height x Width x Depth 400 x 255 x 320 mm / 15.5“ x 10“ x 12.5“
Warranty 5 years
Operating temperature 0° C to 40° C (32° F to 104° F)
Storage temperature -30° C to 70° C (-22° F to 167° F)
Humidity Max. 90 % not condensing
1=longtermIEC265-8-Wrms/10min
2=nominalIEC265-8=PeakPower5µsec
3=payattentiontotheselectedvoltageontherearsideofthespeaker

Adam A8X Specifications

General

Frequency Response	38 Hz - 50 kHz
Amplifier Power Tweeter	50 W
Type	Active Studio Monitor
Input Connectors	XLR
Input Impedance	10 kΩ
Tweeter Type	X-ART tweeter
Amplifier Power Woofer	150 W (RMS)
