Connecting SCSI Devices
Maximum Cable Lengths
The total length of cabling (internal and external) on the SCSI bus
cannot exceed the maximum lengths listed in the following table.
❒
Maximum
Cable Length Data Transfer Rate
Maximum
Devices
Supported
25 m (82 ft) Ultra160 SCSI (160 MBytes/sec)
Ultra2 SCSI (80 MByte/sec)
1
12 m (39.4 ft) Ultra160 SCSI (160 MBytes/sec)
1
Ultra2 SCSI (80 MByte/sec)
1
Mixing Fast/Ultra devices with Ultra160 SCSI devices causes the entire SCSI bus to
default to Ultra SCSI speeds and cable requirements.
15
3 m (9.8 ft) Fast SCSI (10 MBytes/sec) 7
3 m (9.8 ft) Ultra SCSI
(40 MBytes/sec for 16-bit,
20 MBytes/sec for 8-bit)
4
1.5 m (4.9 ft) Ultra SCSI
(40 MBytes/sec for 16-bit,
20 MBytes/sec for 8-bit)
5-8
2
2
Ultra SCSI data transfer rates do not currently support more than eight devices.
