ADB ALC4-2 - DMX Operation Modes; Standard DMX Mode (5 Channels); Matrix DMX Mode (20 Channels); Extended DMX Mode (21 Channels)

www.adblighting.com User Manual - Page 9
Issue 1.1
DMX Operation – DMX Fonctionnement - DMX Funktionen
– DMX Werking
Mode Standard: 5 Channels
All LED modules have same light output (color & intensity). The Default Open Value for all parameters is 0.
ISIS
Offset 0
Start = 1
Offset 1
DMX Channel
0 1 Dimmer
1 2 CT (Color Temp.)
2 3 Red
3 4 Green
4 5 Blue
Mode Matrix: 20 Channels
This mode gives possibility to drive independently all four LED modules. No General Master for the individual ALC4-2 unit exists.
This mode is designed to be using when creating special effects and chasers, running across multiple units - The Default Open Value for all
parameters is 0.
ISIS
Offset 0
Start = 1
Offset 1
DMX Channel
0 1 Dimmer
Module 1
1 2 CT
2 3 Red
3 4 Green
4 5 Blue
5 6 Dimmer
Module 2
6 7 CT (Color Temp.)
7 8 Red
8 9 Green
9 10 Blue
10 11 Dimmer
Module 3
11 12 CT (Color Temp.)
12 13 Red
13 14 Green
14 15 Blue
15 16 Dimmer
Module 4
16 17 CT (Color Temp.)
17 18 Red
18 19 Green
19 20 Blue
Mode Extended: 21 Channels
All 4 modules can be addressed independently to create special effects.
A general master channel controls the overall intensity of all four LED modules for unit control. - The Default Open Value for all parameters is 0.
ISIS
Offset 0
Start = 1
Offset 1
DMX Channel
0 1 Master (Module 1 to 4)
1 2 Dimmer
Module 1
2 3 CT
3 4 Red
4 5 Green
5 6 Blue
6 7 Dimmer
Module 2
7 8 CT (Color Temp.)
8 9 Red
9 10 Green
10 11 Blue
11 12 Dimmer
Module 3
12 13 CT (Color Temp.)
13 14 Red
14 15 Green
15 16 Blue
16 17 Dimmer
Module 4
17 18 CT (Color Temp.)
18 19 Red
19 20 Green
20 21 Blue
