ACCESS IDENTIFIER
Summary:
Circuits displayed in the Craft Interface are identified by the Access Identifier (AID).
Figure 106-1 shows an example of a circuit with descriptions of each part of the AID. The DS3
signal is demultiplexed by the DS3 MUX into 28 DS1 signals and seven DS2 signals. See Table
106-1 for DS1 signal routing details. See Table 106-2 for DS2 signal routing details. See Figure
106-2 for chassis slot numbering.
T1-1-7-2-1
Shelf Number Group Number: 1, 2, 3, 4, 5, 6, or 7
Site or Loop Number: 1 (Local or HDSL
Loop 1) or 2 (Remote or HDSL Loop 2)
Slot Number: 1, 2, 3, or 4
Circuit Identifier:
(T1, T2, T3 or HDSL)
CIRCUIT AID
EQUIPMENT AID
EQPT-LIU1-7-2-1
Equipment Type (LIU, MPU, MXP, MXW, TAU or EXT) and Shelf Number
Identifier for Equipment AID
Group Number: 1, 2, 3, 4, 5, 6, or 7
Slot Number: 1, 2, 3, or 4
Site or Loop Number: 1 (Local or HDSL
Loop 1) or 2 (Remote or HDSL Loop 2)
LIU = Line Interface Unit
MPU = Main Processor Unit
MXP = DS3 MUX (Protect)
MXW = DS# MUX (Working)
TAU = Remote Test Access Unit (RTAU)
EXT = External
14852-A
Figure 106-1. Access Identifier Display
