PRE-INSTALLATION AND CODE REQUIREMENTS Continued
Air Handler Evaporator Blower Performance
External Static Pressure – Inches H
2
O
0.4 0.6 0.8 1.0 1.2 1.4 1.6
Model CFM R.P.M. B.P.H. R.P.M. B.P.H. R.P.M. B.P.H. R.P.M. B.P.H. R.P.M. B.P.H. R.P.M. B.P.H. R.P.M. B.P.H.
400 780 0.2 900 0.2 1,030 0.2 1,150 0.2 1,240 0.3 1,320 0.3 1,410 0.3
VCA/HCA
500 840 0.2 960 0.2 1,060 0.2 1,170 0.2 1,260 0.3 1,330 0.3 1,430 0.4
051
600 870 0.2 990 0.2 1,090 0.2 1,190 0.3 1,270 0.3 1,350 0.3 1,440 0.4
700 940 0.2 1,030 0.2 1,120 0.3 1,220 0.3 1,300 0.4 1,380 0.4 1,450 0.4
500 720 0.2 840 0.2 960 0.2 1,060 0.2 1,160 0.2 1,260 0.3 1,340 0.3
VCA/HCA
600 750 0.2 860 0.2 980 0.2 1,080 0.2 1,770 0.3 1,270 0.3 1,350 0.3
071
700 800 0.2 890 0.2 1,000 0.2 1,090 0.3 1,190 0.3 1,280 0.4 1,360 0.4
800 840 0.2 930 0.2 1,040 0.3 1,110 0.3 1,210 0.4 1,290 0.4 1,370 0.5
900 890 0.3 970 0.3 1,070 0.3 1,150 0.4 1,230 0.5 1,300 0.5 1,380 0.5
900 610 0.2 720 0.3 820 0.3 910 0.3 990 0.4 1,050 0.5 1,120 0.5
VCA/HCA
1,100 640 0.2 750 0.3 840 0.3 930 0.4 1,020 0.4 1,080 0.5 1,140 0.6
101
1,300 660 0.2 760 0.3 850 0.4 950 0.4 1,030 0.5 1,090 0.6 1,160 0.7
1,500 680 0.3 780 0.3 870 0.4 960 0.5 1,040 0.6 1,100 0.7 – –
1,100 650 0.2 770 0.3 860 0.3 940 0.4 1,020 0.5 1,090 0.6 1,160 0.6
VCA/HCA
1,400 700 0.3 800 0.3 880 0.4 960 0.5 1,040 0.7 1,120 0.7 1,180 0.8
141
1,700 740 0.4 820 0.5 900 0.6 980 0.7 1,050 0.8 1,130 0.8 1,200 0.9
2,000 790 0.5 860 0.6 940 0.7 1,010 0.8 1,080 0.9 1,140 1.0 – –
1,500 480 0.3 590 0.3 670 0.4 740 0.5 810 0.6 860 0.7 920 0.8
VCA/HCA
2,000 510 0.4 600 0.5 680 0.6 750 0.6 820 0.8 870 0.9 930 1.1
201
2,500 550 0.5 630 0.6 690 0.7 760 0.8 830 1.0 880 1.2 940 1.3
3,000 580 0.7 650 0.8 720 0.9 780 1.1 840 1.3 890 1.5 – –
2,500 550 0.4 630 0.6 690 0.7 760 0.8 820 1.0 880 1.2 940 1.3
VCA/HCA
3,000 580 0.7 650 0.8 720 0.9 780 1.1 830 1.3 890 1.4 950 1.6
271
3,500 630 0.9 690 1.1 740 1.2 800 1.4 850 1.6 910 1.7 960 1.9
4,000 650 1.2 730 1.4 780 1.5 820 1.7 870 1.8 – – – –
3,200 530 0.6 600 0.7 660 0.8 720 1.0 780 1.2 840 1.3 900 1.5
VCA/HCA
3,800 570 0.8 620 1.0 680 1.2 750 1.3 800 1.5 850 1.7 910 1.8
361
4,400 600 1.2 660 1.3 720 1.5 770 1.7 820 1.8 870 2.1 920 2.3
5,000
640 1.6 700 1.7 750 1.8 800 2.1 850 2.4 900 2.6 940 2.7
Notes:
Unshaded areas for “S” Models.
Light Gray shaded areas for “M” Models. Dark Gray shaded areas for “L” Models.
Tables can be interpolated but not extrapolated.
Table 5
