6
Components
1. Control panel
2. Carrying handle
3. Air outlet
4. Air lter
5. Exhaust air outlet
6. Air lter
7. Water stopper/
drainage point
8. Air inlet
9. Cord storage
10. Air inlet
Accessories
11. Exhaust hose
12. Flat Type Adaptor - for insertion over
hose & connected with PVC window kit
(or into hole in the wall/window).
13. I nward adaptor (connected unit &
exhaust hose)
14. PVC Window Kit 1 - for lling the open
window space
15. PVC Window Kit 2 - for lling the open
window space
16. PVC Window Kit 3 - for lling the
open window space and with hole for
connection to exhaust hose.
17. Drain tube for continuous drainage
18. Active carbon lter
19. Remote control
2
7
1
3
10
9
8
4
5
6
