ADE M320600-01 - Key pad; Weighing platform from underneath

6 M320600-01-160525-Rev002-UM-e
Key pad
Name
Description
HOLD
Confirms the height input
Activates the auto-hold function.
Activates the mother/child function.
BMI
Press while standing on the scale in order to proceed BMI mode
Activates the tare function.
Turning
During operation this key is being used to turn around the displayed figures. Second function
of this key is to switch the scale on.

Use this key in BMI mode to switch between the numbers downwards.
UNIT
Press in order to switch the units between kg and lb

Use this key in BMI mode to switch between the numbers upwards.
Weighing platform from underneath
Hole for mounting screw ‘A’
Battery compartment
Levelling feet
Power socket
