ADE WS 1703 User Manual

57
Weather Station with Wireless Outdoor Sensor WS 1703
English
Setting the time and date manually
If there is more than approx. 20seconds between
two pushes of a button, the setting process
automatically ends and you will have to repeat it.
1. Press and hold the MODE button until the indicator for
the 12- and 24-hour time format blinks on the display.
2. Using the + and - buttons, set the desired time format
(“12 hr” or “24 hr”).
3. Press MODE to save the setting. The temperature unit
blinks on the display.
4. Proceed as previously described.
5. Press MODE each time to save the settings.
6. Press the + or - button to set the desired value.
7. Carry out the following settings:
− Temperature unit
− Air pressure unit
− Time zone in which you are located (for Germany,
choose 00)
− Hours
− Minutes
− Date format
− Year
− Month
− Day
− Language (relates exclusively to the weekday
indicator)
8. Finally, press MODE to conclude the procedure.
FW Station.indb 57 26.04.2017 10:02:46

ADE WS 1703 Specifications

General

Display type	LED
Built-in display	Yes
Product color	Wood
Housing material	Acrylonitrile butadiene styrene (ABS), Bamboo
Measuring functions	Indoor hygrometer, Indoor thermometer, Outdoor hygrometer, Outdoor thermometer
Outdoor sensors range	60 m
Temperature measurement units	F, °C
Measuring functions trend display	Hygrometer, Thermometer
Humidity measuring range (outside) (H-H)	20 - 95 %
Temperature measurement range (outside) (T-T)	-20 - 50 °C
Battery type	AAA
Power source	Battery
Battery voltage	1.5 V
Transmission frequency	0.433 GHz
Connectivity technology	Wired

Weight and Dimensions

Depth	53 mm
Width	165 mm
Height	122 mm
