ADE WS 1703 User Manual

58
Weather Station with Wireless Outdoor Sensor WS 1703
Starting signal reception manually
If the radio signal symbol to the left is no longer
displayed, the radio signals from the time signal
transmitter are no longer being received. The time
indicator nevertheless continues precisely.
Press and hold the + button until the radio signal symbol
is displayed again. The signal reception is thus started
manually. Pay attention to the following:
 If the reception was not successful, the reception
symbol fades out after a few minutes and the time on
the display continues normally.
 Upon successful signal reception, the radio-controlled
alarm clock adjusts itself to the time of the time signal
transmitter. If you have already carried out manual
time and date settings, these will be automatically
adjusted.
Choosing a location
NOTE on material damage
 Protect the base station and wireless sensor
from dust, impacts, extreme temperatures
and direct sunlight.
 Protect the base station from moisture.
Position the base station exclusively in a dry,
closed room. The wireless sensor is protected
against moisture, but must be protected
from direct exposure to moisture, e.g. rain.
FW Station.indb 58 26.04.2017 10:02:46

ADE WS 1703 Specifications

General

Display type	LED
Built-in display	Yes
Product color	Wood
Housing material	Acrylonitrile butadiene styrene (ABS), Bamboo
Measuring functions	Indoor hygrometer, Indoor thermometer, Outdoor hygrometer, Outdoor thermometer
Outdoor sensors range	60 m
Temperature measurement units	F, °C
Measuring functions trend display	Hygrometer, Thermometer
Humidity measuring range (outside) (H-H)	20 - 95 %
Temperature measurement range (outside) (T-T)	-20 - 50 °C
Battery type	AAA
Power source	Battery
Battery voltage	1.5 V
Transmission frequency	0.433 GHz
Connectivity technology	Wired

Weight and Dimensions

Depth	53 mm
Width	165 mm
Height	122 mm
