Industrial Electronic Devices
ADFweb.com S.r.l.
Document code: MN67507_ENG Revision 2.400 Page 2 of 45
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLES OF CONNECTION 4
CONNECTION SCHEME 6
CHARACTERISTICS 13
CONFIGURATION 13
POWER SUPPLY 14
FUNCTION MODES 15
LEDS (for HD67507-A1 and HD67507-B2) 16
LEDS (for HD67507-Slim-xxx) 17
LEDS (for HD67507-WiFi-B2) 18
ETHERNET 19
WI-FI 19
RS232 20
RS485 21
RS422 22
USE OF COMPOSITOR SW67507 23
NEW PROJECT / OPEN PROJECT 24
SOFTWARE OPTIONS 25
SET COMMUNICATION 26
OPERATION MODE 33
TRANSLATE TABLE 34
UPDATE VIA UDP 36
MECHANICAL DIMENSIONS 38
ORDERING INFORMATIONS 42
ACCESSORIES 43
DISCLAIMER 44
OTHER REGULATIONS AND STANDARDS 44
WARRANTIES AND TECHNICAL SUPPORT 45
RETURN POLICY 45
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that you
need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code” that
appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/ and
search for the corresponding code on the page. Click on the proper “Document
Code” and download the updates.
REVISION LIST:
Revision Date Author Chapter
Description
2.100 14/07/2014
Ff All Added chapters
2.200 27/12/2017
Ff All New Hardware for Wi-Fi
2.300 04/01/2023
Ff All Added Slim version
2.400 26/01/2023
Ff All New Hardware for Wi-Fi
WARNING:
ADFweb.com reserves the right to change information in this manual about our
product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective owners.
