ADF 100 DUO - Technical Specifications

6
3- Technical Specification
Specifications
TESTED IN ACCORDANCE WITH
AS/NZS 4012:2014 & AS/NZS 4013:2014
Burning Harwood
Unit
ADF
DUO
100
Maximum Avearge Heat Output kW 18.9
Maximum Peak Heat Output kW 20.4
Overall Average Efficiency % 60
Particulate Emission Factor g/kg 1.1
Maximum firewood load kg 10
Minimum clearance distances from combustible materials mm
See page
11.
Flue Diameter mm 200
Recommended Fuel
Burn only Harwood
Moisture ≤ 20%
Electrical Specification – Note optional Fan requires
specific bench requirements and a wall mount control
W
36
V
220-240
Hz
50/60
Fan Settings
Variable speed from 2 to 8
Model
Dimensions (mm)
Width Depth Height Weight
ADF100 DUO 100 Linea (NMV-B) Freestanding
1010
550
565
220kg
