9. INSTALLER MENU FOR ADJUSTING CONTROL PARAMETERS
Only Qualified Personnel must access this MENU, because changing the set of parameters
could make the product completely unsuitable for the application.
• To enter this Menu, Press the MENU and DOWN button at the same time for 3 Seconds.
• Scroll through the parameter Codes by pressing the Up and Down buttons.
• To view the current value of the code, and to adjust, press the Menu Key.
• To modify the value, use the Up and Down buttons.
• To save the new value, press the MENU key.
• To exit without saving a new value, Press the ON/OFF button.
• Press the ON/OFF button again to exit the MENU (or wait 60 seconds).
Description
Cod.
Min
Set
Max
U.M.
Air Thermostat for Fan Activation
E01
30
45
100
[°C]
Air Thermostat for SAFETY
E02
80
100
140
[°C]
Air Thermostat for ALARM
E03
100
120
180
[°C]
Air Thermostat for FAN SAFETY
E04
100
135
180
[°C]
Air Thermostat for Valve Opening
E05
20
30
140
[°C]
Air Thermostat for Valve Closure
E06
20
80
140
[°C]
Air Thermostat for SERVICE output Activation
E07
20
50
180
[°C]
Temperature Delta for Proportional management
E50
20
20
100
[°C]
Hysteresis Thermostat for fan Activation
IE01
1
2
40
[°C]
Hysteresis Thermostat for SAFETY
IE02
1
2
40
[°C]
Hysteresis Thermostat for ALARM
IE03
1
2
40
[°C]
Hysteresis Thermostat for FAN SAFETY
IE04
1
2
40
[°C]
Hysteresis Thermostat for Valve Opening
IE05
1
2
40
[°C]
Hysteresis Thermostat for Valve Closure
IE06
1
2
40
[°C]
Hysteresis Thermostat for SERVICE output Activation
IE07
1
2
40
[°C]
Hysteresis Ambient Thermostat
Ib01
0
1
20
[°C]
P01 Fan Speed (minimum)
UA01
20
1
100
[%]
P09 Fan Speed (ninth)
UA09
80
1
100
[%]
P10 Fan Speed (maximum)
UA10
100
1
100
[%]
Delay time for Air Damper closure
t 06
0
10
120
[min]
Audible alarm suspension time
t 07
1
5
60
[min]
Time for the Fan Accelerator function
t 08
0
2
10
[sec]
S2 Input Configuration
P01
0
0
2
n
SERVICE Output Configuration
P02
0
0
3
n
Enable FAN SAFETY
P03
0
1
1
n
Enable Air SAFETY
P04
0
1
1
n
Enable Air ALARM
P05
0
1
1
n
Enable “Start” Function of Air Damper
P12
0
0
1
n
NOTE: if you modify UA01, UA09, UA10, the Fan immediately works at the speed you are calibrating, showing the effect
of calibration
