ADF NMV Series - Technical Specification

6
3- Technical Specification
Specifications
TESTED IN ACCORDANCE WITH
AS/NZS 4012:2014 & AS/NZS 4013:2014
Burning Harwood
Unit 820 1000
Maximum Avearge Heat Output kW 9.7 12.5
Overall Average Efficiency % 63 64
Particulate Emission Factor g/kg 0.8 1.2
Maximum firewood load kg 9.7 13.7
Minimum clearance distances from combustible materials mm
See page
10/15.
See Page
10/15.
Flue Diameter mm 200 200
Recommended Fuel
Burn only Harwood
Moisture ≤ 20%
Electrical Specification
W
36
V
220-240
Hz
50/60
Fan Settings
Thermostat Low, Manual High.
Model
Dimensions (mm)
Width Depth Height Weight
ADF820NM-RS Freestanding
with Bench
832 445 860 198
ADF820NM-RS Freestanding
with Bench and Fan
832 445 860 200
ADF820NMV-B Freestanding
with Fan
832 450 565 160
ADF1000NMV-B Freestanding
1012
450
465
172
ADF1000NMV-B Freestanding
with Fan
1012 450 565 174
ADF1000NMV-P
Pedestal Freestanding
1012 450 865 206
