SYMBOLOGY ON THE MACHINE
Symbol denoting the solution valve.
Indicates the solution valve lever.
Symbol denoting the lever of the emergency
and parking brake.
Indication of the maximum temperature of the
solution detergent.
It is placed near the charging hole of the
solution tank.
Symbol denoting the maximum capacity level
reached in the solution tank visible through the
level hose.
Symbol denoting the lowering of the squeegee.
Symbol denoting the halfway
capacity level
reached in the solution tank, visible through the
level hose.
Symbol denoting the lifting of the squeegee.
Symbol denoting the minimum
capacity level
reached in the solution tank, visible through the
level hose.
SYMBOLOGY ON THE MANUAL
Symbol denoting the open book.
Indicates that the operator has to read the
manual before the use of the machine.
Symbol that indicates the obligation of wearing
safety glasses.
Symbol denoting the open book.
For the good functioning of the on-board
battery charger (optional), read the manual of
the constructor.
Symbol that indicates the obligation of wearing
safety gloves.
Warning symbol.
Read carefully the sections marked with this
symbol, for the security of both the operator
and the machine.
Symbol that precedes an important information
about the proper use of the machine.
Symbol that indicates the obligations of
disconnecting the system from the batteries by
disconnecting the connector
before operating
on the machine.
Symbol that indicates operations that have to
be carried out only by qualified personnel.
OPTIONAL ACCESSORIES
The optional accessories are:
3S – Solution Saving System (1);
On-board battery charger (2).
