ADJ DOTZ TPAR - 18 Channel DMX Mode Functions

ADJ Products, LLC - www.adj.com - Dotz TPar System User Manual Page 19ADJ Products, LLC - www.adj.com - Dotz TPar System User Manual Page 18
Channel Value Function
1 RED 1
0 - 255 0% - 100%
2 GREEN 1
0 - 255 0% - 100%
3 BLUE 1
0 - 255 0% - 100%
4 RED 2
0 - 255 0% - 100%
5 GREEN 2
0 - 255 0% - 100%
6 BLUE 2
0 - 255 0% - 100%
7 RED 3
0 - 255 0% - 100%
8 GREEN 3
0 - 255 0% - 100%
9 BLUE 3
0 - 255 0% - 100%
10 RED 4
0 - 255 0% - 100%
11 GREEN 4
0 - 255 0% - 100%
12 BLUE 4
0 - 255 0% - 100%
13 COLOR MACROS & PROGRAMS
0 - 15 NO FUNCTION
16 - 23 RED
24 - 31 GREEN
32 - 39 BLUE
40 - 47 RED & GREEN
48 - 55 GREEN & BLUE
56 - 63 RED & BLUE
64 - 71 RED, GREEN, & BLUE
72 - 79 COLOR 1
Dotz TPar System 18 Channel Mode
Channel Value Function
13 COLOR MACROS & PROGRAMS
80 - 87 COLOR 2
88 - 95 COLOR 3
96 - 103 COLOR 4
104 - 111 COLOR 5
112 - 119 COLOR 6
120 - 127 COLOR 7
128 - 135 COLOR 8
136 - 143 COLOR FADE 1
144 - 151 COLOR SNAKE
152 - 159 COLOR FADE 2
160 - 167 COLOR CHANGE
168 - 175 COLOR FLOW 1
176 - 183 COLOR FLOW 2
184 - 191 COLOR FLOW 3
192 - 199 COLOR FLOW 4
200 - 207 COLOR FLOW 5
208 - 215 COLOR FLOW 6
216 - 223 COLOR FLOW 7
216 - 223 COLOR FLOW 7
224 - 231 COLOR FLOW 8
232 - 239 COLOR FLOW 9
240 - 255 SOUND ACTIVE
14 MASTER DIMMER/PROGRAM SPEED/
SOUND SENSITIVITY
0 - 255 MASTER DIMMER 0% - 100%
0 - 255 PROGRAM SPEED SLOW - FAST
0 - 255 SOUND SENSITIVITY LEAST - MOST
15 STROBING
0 - 255 SLOW - FAST
16 DIMMER CURVES
0 - 41 STANDARD
42 - 84 STAGE
85 - 127 TV
Dotz TPar System 18 Channel Mode
