ADJ DOTZ TPAR - DMX Modes: 9 and 12 Channel; 12 Channel Mode Functions

ADJ Products, LLC - www.adj.com - Dotz TPar System User Manual Page 16 ADJ Products, LLC - www.adj.com - Dotz TPar System User Manual Page 17
When Channel 4 is being used between the values of 16-135,
Channel 5 will control the dimming.
When Channel 4 is being used between the values of 136-239,
Channel 5 will control the speed of the programs.
When Channel 4 is being used between the values of 240-255,
Channel 5 will control sound sensitivity.
If extra lights are attached to the top of the bar, Channels 8 & 9
will control the lights.
Channel Value Function
4 COLOR MACROS & PROGRAMS
224 - 231 COLOR FLOW 8
232 - 239 COLOR FLOW 9
240 - 255 SOUND ACTIVE
5 MASTER DIMMER/PROGRAM SPEED/
SOUND SENSITIVITY
0 - 255 MASTER DIMMER 0% - 100%
0 - 255 PROGRAM SPEED SLOW - FAST
0 - 255 SOUND SENSITIVITY LEAST - MOST
6 STROBING
0 - 255 SLOW - FAST
7 DIMMER CURVES
0 - 41 STANDARD
42 - 84 STAGE
85 - 127 TV
128 - 170 ARCHITECTURAL
171 - 213 THEATER
214 - 255 DEFAULT TO UNIT CURVE SETTING
8 LIGHT 1 (IF APPICABLE)
0 - 127 LIGHT 1 OFF
128 - 255 LIGHT 1 ON
9 LIGHT 2 (IF APPICABLE)
0 - 127 LIGHT 2 OFF
128 - 255 LIGHT 2 ON
Dotz TPar System 9 Channel Mode
Channel Value Function
1 RED 1
0 - 255 0% - 100%
2 GREEN 1
0 - 255 0% - 100%
3 BLUE 1
0 - 255 0% - 100%
4 RED 2
0 - 255 0% - 100%
5 GREEN 2
0 - 255 0% - 100%
6 BLUE 2
0 - 255 0% - 100%
7 RED 3
0 - 255 0% - 100%
8 GREEN 3
0 - 255 0% - 100%
9 BLUE 3
0 - 255 0% - 100%
10 RED 4
0 - 255 0% - 100%
11 GREEN 4
0 - 255 0% - 100%
12 BLUE 4
0 - 255 0% - 100%
Dotz TPar System 12 Channel Mode
