ADJ DOTZ TPAR - DMX Channel Mode Functions; 3 Channel Mode; 5 Channel Mode; 9 Channel DMX Mode Functions

ADJ Products, LLC - www.adj.com - Dotz TPar System User Manual Page 15
ADJ Products, LLC - www.adj.com - Dotz TPar System User Manual Page 14
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 COLOR MACROS & PROGRAMS
0 - 15 NO FUNCTION
16 - 23 RED
24 - 31 GREEN
32 - 39 BLUE
40 - 47 RED & GREEN
48 - 55 GREEN & BLUE
56 - 63 RED & BLUE
64 - 71 RED, GREEN, & BLUE
72 - 79 COLOR 1
80 - 87 COLOR 2
88 - 95 COLOR 3
96 - 103 COLOR 4
104 - 111 COLOR 5
112 - 119 COLOR 6
120 - 127 COLOR 7
128 - 135 COLOR 8
136 - 143 COLOR FADE 1
144 - 151 COLOR SNAKE
152 - 159 COLOR FADE 2
160 - 167 COLOR CHANGE
168 - 175 COLOR FLOW 1
176 - 183 COLOR FLOW 2
184 - 191 COLOR FLOW 3
192 - 199 COLOR FLOW 4
200 - 207 COLOR FLOW 5
208 - 215 COLOR FLOW 6
216 - 223 COLOR FLOW 7
Dotz TPar System 9 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
Dotz TPar System 3 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 LIGHT 1 (Installed on top of the bar)
0 - 127 OFF
128 - 255 ON
5 LIGHT 2 (Installed on top of the bar)
0 - 127 OFF
128 - 255 ON
Dotz TPar System 5 Channel Mode
