TECHNICAL SPECIFICATIONS
M-101HD HEAVY DUTY PROFESSIONAL MIRROR BALL MOTOR
INDOOR USE ONLY
FOR USE WITH UP TO 20-INCH (51cm) MIRROR BALL
MAX LOAD 22 lbs. (10kg)
ROTATION SPEED:
0.8 to 1 RPM (Not Adjustable)
DIMENSIONS
Diameter: 7.50” (190 mm)
Horizontal Height: 5.25” (133 mm)
ELECTRICAL / THERMAL
AC 100-120V - 50/60Hz
Maximum Power Consumption: 4W
Ta = 25° Tb= 30°
M-1616 16” MIRROR BALL
INDOOR USE ONLY
DIMENSIONS
Diameter: 16” (406 mm)
Weight: 6.94 lbs. (3.15 kg)
PL-1000 Pinspot Par Light
INDOOR USE ONLY
Par 36 Metal Pinspot with screw on front cap and 4-foot power cord (no fuse protection)
DIMENSIONS/LAMP
Dimensions: 6.75x5.25” (171x133mm)
Weight: 3.2 lbs. (1.45 kg)
Lamp: 4515 6V 30W, Par 36
Specifications subject to change without any prior written notice.
OPTIONAL ACCESSORIES
Safety Cable with 60-pound weight rating
Truss O-Clamp available in 3 sizes: 2, 1.5, & 1
Replacement Lamp: 6V 30W Halogen PAR-36 – LL-4515
PinPoint Go Color is 5-Watt RGBA LED pinspot
