A.D.J. Supply Europe B.V. – www.americandj.eu – Mega Tri BAR Instruction Manual Page 18
SPECIFICATIONS
MODEL:
Mega Tri Bar™
Working Position: Any safe working position
Voltage: 90V~240V 50/60Hz
LEDs: 18 x 3W Tri Color LEDs
Power
Consumption:
80 Watts
Beam Angle: 40 Degrees
Fuse: 2Amp
Weight:
Dimensions:
Colors:
DMX Channels:
13.2lbs./ 6Kgs.
43.3” (L) x 3.14” (W) x 4.56” (H)
1100 (L) x 80 (W) x 116 (H) mm
RGB Color Mixing
7 DMX Channel Modes
Auto Sensing Voltage: This fixture contains a electronic ballast, which will auto sense the
voltage when it is plugged into the power source.
Please Note: Specifications and improvements in the design of this unit and this manual are
subject to change without any prior written notice.
