ADJ MEGA TRIPAR PROFILE PLUS - Page 11

Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 UV
0 - 255 0% - 100%
5 SHUTTER/STROBE
0 - 31 LED OFF
32 - 63 LED ON
64 - 95 STROBING SLOW - FAST
96 - 127 LED ON
128 - 159 STROBE PULSE SLOW - FAST
160 - 191 LED ON
192 - 223 RANDOM STROBE SLOW - FAST
224 - 255 LED ON
6 MASTER DIMMER
0 - 255 0% - 100%
7 PROGRAM SELECTION MODE
0 - 51 DIMMING MODE
52 - 102 COLOR MACRO MODE
103 - 153 COLOR CHANGE MODE
154 - 204 COLOR FADE MODE
205 - 255 SOUND ACTIVE MODE
8 COLOR MACROS/PROGRAMS/
SOUND ACTIVITY
0 - 255 COLOR MACRO MODE
(See page 24 for the Color Macro Chart)
COLOR CHANGE PROGRAMS
0 - 15 COLOR CHANGE 1
16 - 31 COLOR CHANGE 2
32 - 47 COLOR CHANGE 3
Mega Flat TRI PAK PLUS 10 Channel Mode
ADJ Products, LLC - www.adj.com - Mega Flat TRI PAK PLUS User Manual Page 20 ADJ Products, LLC - www.adj.com - Mega Flat TRI PAK PLUS User Manual Page 21
Channel Value Function
8 COLOR MACROS/PROGRAMS/
SOUND ACTIVITY
SOUND ACTIVE PROGRAMS
0 - 15 SOUND ACTIVE MODE 1
16 - 31 SOUND ACTIVE MODE 2
32 - 47 SOUND ACTIVE MODE 3
48 - 63 SOUND ACTIVE MODE 4
64 - 79 SOUND ACTIVE MODE 5
80 - 95 SOUND ACTIVE MODE 6
96 - 111 SOUND ACTIVE MODE 7
112 - 127 SOUND ACTIVE MODE 8
128 - 143 SOUND ACTIVE MODE 9
144 - 159 SOUND ACTIVE MODE 10
160 - 175 SOUND ACTIVE MODE 11
176 - 191 SOUND ACTIVE MODE 12
192 - 207 SOUND ACTIVE MODE 13
208 - 223 SOUND ACTIVE MODE 14
224 - 239 SOUND ACTIVE MODE 15
240 - 255 SOUND ACTIVE MODE 16
9 PROGRAM SPEED/SOUND SENSITIVE
0 - 255 SLOW - FAST
0 - 255 LEAST SENSITIVE - MOST SENSITIVE
Mega Flat TRI PAK PLUS 9 Channel Mode
When Channel 7 is between the values of 0-51, Channels 1-4 are used, and
Channel 5 will control strobing.
When Channel 7 is between the values of 52-102, Channel 8 is in Color Macros
Mode, and Channel 5 will control strobing.
When Channel 7 is between the values of 103-153, Channel 8 is in Color Change
Mode, and Channel 9 will control the color change speed.
When Channel 7 is between the values of 154-204, Channel 8 is in Color Fade
Mode, and Channel 9 will control the color fade speed.
When Channel 7 is between the values of 205-255, Channel 8 is in Sound Active
Mode, and Channel 9 will control the sound sensitivity.
