68 BIOS Setup
Feature Options Description
Platform hierarchy
Disable
Enable
Enable or Disable Platform Hierarchy
Storage Hierarchy
Disable
Enable
Enable or Disable Storage Hierarchy
Endorsement Hierarchy
Disable
Enable
Enable or Disable Endorsement Hierarchy
TPM2.0 UEFI Spec Version
TCG_1_2
TCG_2
Select the TCG2 Spec
Version Support, TCG_1_2:
the Compatible mode for Win8/Win10,
TCG_2: Support new TCG2 protocol and event format
for Win10 or later
Physical Presence Spec Version
1.2
1.3
Select to Tell O.S. to support PPI Spec Version 1.2 or
1.3.
Note some HCK tests might not support 1.3.
TPM 20 Interface Type Info only
7.3.15. Advanced > AMI Graphic Output Protocol Policy
Feature Options Description
Intel (R) Graphics Controller Info Only
Intel (R) GOP Driver Info Only
Output Select DVI Output Interface
7.3.16. Advanced > SDIO Configuration
Feature Options Description
SDIO Configuration Info Only
SD Card/GPIO MODE
GPIO
SD Card
Select SD Card or GPIO function.
SDIO Access Mode
Auto
ADMA
SDMA
PIO
Auto Option: Access SD device in DMA mode if
controller supports it,otherwise in PIO mode.DMA
Option: Access SD device in DMA mode.PIO Option:
Access SD device in PIO mode.
Mass Storage Devices: Info Only
Sdio Device 1 Details: Info Only
Bus 0 Dev 1c Func 0 Info Only
MMC – xxxx(xx.xGB)
Auto
Floppy
Forced FDD
Hard Disk
Mass storage device emulation type. 'AUTO'
enumerates devices less than 530MB as floppies.
Forced FDD option can be used to force HDD
formatted drive to boot as FDD.
