ADT 927 - Figure 3-11. Tube with O-Rings; Figure 3-12. Filter Element-Extracting Tool

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
ix
Note: For the next action it is recommended your hand are dry (not slippery),
or use a piece of cloth or paper.
Pull out the white tube with O-rings.
Figure 3-11. Tube with O-rings
Push the provided filter element-extracting tool into the filter
element, and close its nut until the tool catches the filter element.
Figure 3-12. Filter element-extracting tool
Pull the filter element up an out.
Release the tool from the filter element by releasing its nut.
Remove the while tube with O-rings from the bottom of the filter
element.
To close the filter:
Inspect the O-rings of the white tube and of the filter body.
Tool nut
