*57 FUNCTION KEY PROGRAMMING
Option Function A B C D Comments
01 Paging
02 Time Display
03 Arm AWAY
04 Arm STAY
05 Arm NIGHT-STAY
06 Step Arming
07 Device Activation Device:
08 Comm. Test
09 Macro Key 1
10 Macro Key 2
11 Macro Key 3
12 Macro Key 4
00 Emergency Keys:
Personal Emergency
Silent Alarm
Audible Alarm
Fire
Emergency Keys: A = [1] / [
]B = [
] / [#] C = [3] / [#]
OUTPUT RELAYS/POWERLINE CARRIER DEVICES WORKSHEET FOR
79,
80 and
81.
Applicable only if Relays and/or Powerline Carrier Devices are to be used.
79 RELAY/POWERLINE CARRIER DEVICE MAPPING (Must program before using *80)
OUTPUT TYPE OUTPUT TYPE
Relay X10 Relay X10
Output
No.
Module
Addr.
Pos
(1-4)
Unit
No.
Description
Output
No.
Module
Addr.
Pos
(1-4)
Unit
No.
Description
01 09
02 10
03 11
04 12
05 13
06 14
07 15
08 16
17
On-Board Trigger 1
18
On-Board Trigger 2
81 ZONE LISTS FOR OUTPUT DEVICES
Fill in the required data on the worksheet below and follow the procedure in the installation manual as you enter the
data during the displays and prompts that appear in sequence.
Note:
Record desired zone numbers below, noting that a list may include
any
or
all
of system's zone numbers.
List No. Used For… Contains These Zones…
01
General Purpose (GP)
02
General Purpose
03
Chime-by-Zone or GP
04
Cross Zones or GP
05
Night-Stay Zones or GP
06
General Purpose
07
General Purpose
08
General Purpose
09
Zones activating pager 1
10
Zones activating pager 2
11
Zones activating pager 3
12
Zones activating pager 4
