TO ENTER PROGRAMMING MODE:
Local programming requires the use of a Custom English touchpad connected to the touchpad terminals on the control.
1.
POWER UP, then depress
[
✱
] and [#]
both at once, within 50 seconds of powering up.
OR
2.
Initially, key:
Installer Code
(
6 + 3 + 2 + 1)
plus
8 + 0 + 0.
OR
3.
If different
Installer Code
is programmed, key:
New Installer Code + 8 + 0 + 0.
(if
✱
98 was used to exit previously, method 1 above must be used to enter the program mode again)
Data Field Programming Procedures
Task Procedure
Go to a Data Field
Press [
∗
] + [Field Number], followed by the required entry.
Entering Data
When the desired field number appears, simply make the required entry. When the last
entry for a field is entered, the touchpad beeps three times and automatically displays
the next data field in sequence.
If the number of digits that you need to enter in a data field is less than the maximum
digits available (for example, the phone number fields *41, *42), enter the desired data,
then press [
∗
]. The entry is terminated and the next data field number appears.
Review a Data Field
Press [#] + [Field Number].
Data will be displayed for that field number. No changes will be accepted in this mode.
Deleting an Entry
Press [
∗
] + [Field Number] + [
∗
]. (Applies only to fields
∗
40–*43, *45, *94, and pager
programming fields)
Interactive Mode Programming (∗56, *57, ∗58, ∗80, ∗81, ∗82)
Press
[
✱
] + [Interactive Mode No.]
(for example,
✱
56). The Custom English display touchpad will display the first of a series of
prompts requesting entries.
Interactive Mode Used to Program
✱
56 Zone Programming Zone characteristics, report codes, alpha descriptors, and serial numbers for 5800
RF transmitters.
✱
57 Function Key Programming Unlabeled touchpad keys (known as ABCD keys) for special functions
✱
58 Zone Programming Same options as *56 mode, but with fewer prompts. Intended for those familiar with
(Expert mode) this type of programming, otherwise *56 mode is recommended.
✱
79 Output Device Mapping Assign module addresses and map individual relays/powerline carrier devices
✱
80 Output Programming 4229 or 4204 Relay modules, Powerline Carrier devices, or on-board triggers
✱
81 Zone List Programming Zone Lists for relay/powerline carrier activation, chime zones, pager zones, etc.
✱
82 Alpha Programming Zone alpha descriptors
INITIALIZE DOWNLOAD and RESET DEFAULTS
✱
96
Initializes download ID and subscriber account number.
✱
97
Sets all data fields to original factory default values.
TO EXIT PROGRAMMING MODE:
✱
98
Exits programming mode and
prevents
re-entry by:
Installer Code
+
8
+
0
+
0
. If
✱
98
is used to exit programming
mode, system must be powered down, and method 1 above used to enter the programming mode.
✱
99
Exits programming mode and
allows
re-entry by:
Installer Code
+
8
+
0
+
0
or method 1 above.
Special Messages
OC
= OPEN CIRCUIT (no communication between Touchpad and Control).
EE
or
ENTRY ERROR
= ERROR (invalid field number entered; re-enter valid field number).
After powering up,
AC, dI
(disabled) or
Busy Standby
and
NOT READY
will be displayed after approximately 4 seconds.
This will revert to a “
Ready
” message in approximately 1 minute, which allows PIRS, etc. to stabilize. You can bypass this
delay by pressing
[#] + [0].
If
E4
or
E8
appears, more zones than the expansion units can handle have been programmed. Correct the programming
and then completely de-power and re-power the control to clear this indication and remove the disable indication.
