Adtec RD-71 - Video Menu

Video Menu
Item
Function
Options
Output Menu
Fault Mode
Display or Modify the current SDI
video fault setting. This setting
sets the video resolution when in
video fault.
This setting will be applied on
startup when no video is
present. If video becomes
present, the setting will be
overridden by the current video
setting.
480i59.94
576i50
720p59.94
720p50
1080i59.94
1080i50
1080p59.94
1080p50
Video Loss
When video is not detected on
the configured input, this setting
will define the output.
OFF:No video output on fault
BLANK:Only blanking on fault
BLANKTONES: Blanking and tones
on fault
BLANKOVERLAY: Blanking and
overlay on fault
BLANKTONESOVERLAY
Blanking, tones and overlay on fault
When a type with BLANK is
selected, the current bars/matte
setting will be applied.
When a type with TONES is
selected, the current tones setting
will be applied.
When a type with OVERLAY is
selected, the current device name
will be used.
3G Mapping
Level SDI
SDI 3G Level controls the
mapping of the 3G-SDI signal
when decoding 1080P50,
1080P59.94 and 1080P60
streams. The 3G-SDI signal can
be mapped to Level A or Level B
Dual Link. The mapping is
individually configurable for each
set of outputs (SDI and SDIALT).
A
B
25
