If 3G-SDI output does not
appear on the downstream
device, the device may not
support the currently configured
mapping mode. Use SDI3GLEVEL
to change the mapping mode.
3G Mapping
Level SDIALT
SDI 3G Level controls the
mapping of the 3G-SDI signal
when decoding 1080P50,
1080P59.94 and 1080P60
streams. The 3G-SDI signal can
be mapped to Level A or Level B
Dual Link. The mapping is
individually configurable for each
set of outputs (SDI and SDIALT).
If 3G-SDI output does not
appear on the downstream
device, the device may not
support the currently configured
mapping mode. Use SDI3GLEVEL
to change the mapping mode.
A
B
Downscaling
SDI
The Downscaling SDI setting
determines whether the SDI
bank ( SDI Output 1 and 2 ) will
be output natively or downscaled
to SD.
OFF
SD
Downscaling
SDIALT
The Downscaling SDI setting
determines whether the SDI
bank ( SDI Output 3 and 4 ) will
be output natively or downscaled
to SD.
OFF
SD
Genlock Menu
Genlock Mode
Configures the genlock operation
of the decoder. SLAVE is
primarily used for 3D
applications and REMOTE is used
in standard genlock operation.
OFF - Disables genlock
SLAVE - Enable Genlock, Decode
source is synchronous to SYNC IN
signal
REMOTE - Enable genlock, Decode
source is NOT synchronous to SYNC
IN signal
Horizontal
Adjust
Horizontal adjustment defines
the difference in the SYNC IN
HSYNC and output HSYNC.
Typically, this should be in the
range of 0 to +1 line in clocks.
For example, a 1080I output
could be adjusted from 0 to
0 - 2200
