EXPLANATION OF TERMINAL CONNECTIONS
TERMINAL DESCRIPTION TERMINAL DESCRIPTION
RLY 5 Solid state relay output #5 AC +15 VDC IN Input power for the circuit board
RLY 5 Solid state relay output #5 AC GND Input ground for the circuit board
RLY 4 Solid state relay output #4 AC RLY1 COMM Common toggle for output relay #1
RLY 4 Solid state relay output #4 AC RLY1 NC Normally closed contact for relay #1
RLY 3 Solid state relay output #3 AC RLY1 NO Normally open contact for relay #1
RLY 3 Solid state relay output #3 AC RLY2 COMM Common toggle for output relay #2
INPUT COMM Common input for OPTO, RLY2 NC Normally closed contact for relay #2
PULSE, and RESET inputs
OPTO INPUT Input for photo eye RLY2 NO Normally open contact for relay #2
PULSE INPUT Input for external timing pulses +5 VDC OUT Locally available 5 v source
RESET INPUT Input for external reset button GND Ground for local 5 v source
TERMINAL DESCRIPTION
L IN Power input, hot lead
N IN Power input, neutral lead
G IN Power input, ground lead
SW-L OUT Power output to On/Off switch, hot lead
SW-N OUT Power output to On/Off switch, neutral lead
SW-L IN Switched power from On/Off switch, hot lead
SW-N IN Switched power from On/Off switch, neutral lead
L OUT Power output, hot lead (Used for powering reject devices, etc.)
N OUT Power output, neutral lead (Used for powering reject devices, etc.)
G OUT Power output, ground lead (Used for powering reject devices, etc.)
