Advanced Elements ATTACK PRO - Kayak Deflation and Folding; Deflation Process; Folding Instructions and Cautions

Attack
TM
Pro Inatable Kayak Owner’s Manual
11
3.5 DEFLATION
1. Remove the caps from all 3 chambers, push valve stems inward and rotate to the deate
position. (See Figure 1).
2. Remove foot braces, thigh straps, and seat.
3. Once the chambers are deated you can use your pump to vacuum out any additional air for
improved folding.
3.6 FOLDING
Caution: When the kayak is deated and folded up, creased edge points at the ends of the folds
(pictured below) can be vulnerable. If rubbed hard enough on an abrasive surface it can create a
small rub hole in the material and a potential air leak.
When the kayak is inated, or even unfolded and deated, this is not a concern.
NOTICE: Reverse your pump to completely deate all chambers.
1. Completely deate all air chambers, thoroughly dry kayak and remove the seat and thigh
straps.
2. Fold sides A and B inward.
3. Fold Bow and Stern section inward (C and D).
4. Fold again at line (E).
5. Place into duel bag.
