12. Follow the Wheel Deck Assembly Section. Installation is the same
wether you have the standard or Direct Drive Wheel Deck.
13.
Prepare the Wheel Deck with 4X T-Nuts and 4X M8 X 16 socket screws. Screw
in the T-Nuts no more than a turn.
14.
Slide the Wheel Deck through the top of the Up Post Channels. Fully tighten.
(For the Fanatec side mount option, simply install one side at a time, install your
wheel, and then adjust height with the wheelbase in place)
If the Wheel Deck seems too large for the gap, loosen further the M8x35
screws holding the Up Posts. It is made to fit.
