Specifications & Ordering:
Models, Sales Order Parts:
Part No:
Mxp-024F: 20 Zone LED Card and label fitted to a Mx-4100 control panel
Mxp-025F: 20 Zone LED Card and label fitted to an Mx-4200, Mx-4400 or Mx-4800
Mxp-013-050: 50 Zone LED Card and label fitted to an Mx-4200, Mx-4400 or Mx-4800.
Mxp-013-100: 100 Zone LED Card and label fitted to an Mx-4200, Mx-4400 or Mx-4800
Mxp-013-200: 2x 100 Zone LED Cards and label fitted to an Mx-4200, Mx-4400 or Mx-4800
Spares:
Mxs-024: Replacement 20 Zone LED Card (PCB only)
Mxs-009-050: Replacement 50 Zone LED Card (PCB only).
Mxs-009-100: Replacement 100 Zone LED Card (PCB only).
Applications / Limitations:
The zone indicator card can be fitted to an MxPro 4 control panel to provide indication of the zone(s) in fire in
addition to the panels graphical display. The LED will illuminate when the corresponding zone enters a fire
condition.
The 100 Zone LED card incorporates a DIL switch to set the zone range to be indicated from 1 to 1000. (E.g. 1
100, 101 –200…901 –1000). The 20 and 50 zone cards display zones 1 20 and zones 1 50 respectively.
In the event of more than 50 zones entering a fire condition, the LED’s will change from continuous to flashing
in order to minimise the power drawn from the control panel.
If an Mxp-012 on-board printer is fitted to a panel, and a zone indicator card is also required, use the Mxp-013-
050, Mxp-013-100 or Mxp-013-200 modules. The Mxp-025 20 zone LED card cannot also be used.
Compatibility:
The Mxp-024F can be fitted to an Mx-4100 control panel.
The Mxp-025F, Mxp-013-050F, Mxp-013-100F and Mxp-013-200F can be fitted to an Mx-4200, Mx-4400 or
Mx-4800 control panel.
All Zone Indicator cards are supported from panel software revision 16 onwards.
Item
Specification Details
Panel loading in
Quiescent state
3mA
Panel loading, all
LEDS on
Mxp-013-50F / Mxp-013-100F
Mxp-013-200F
27mA
54mA
Maximum Working
Temperature
50°C
As our policy is one of constant product improvement the right is therefore reserved to modify product specifications without prior notice
