WP-T810 Thermal Printer
12
4 Installations
4.1 How to Connect Power Adapter
1 Ensure that the power switch is OFF.
2 Plug the power connector into the printer’s power connector.
3 Plug the power cord into the outlet, and turn on the power.
4 Connector Specifications shows as below.
Pin Number Signal Name
(1) +24VDC
(2) GND
(3) NC
Shell Frame GND
