WP-T810 Thermal Printer
27
6.4 USB Interface Specifications
1 Specifications
z USB B type/ female
z USB specification 2.0 complaint, full speed mode (12 Mbps).
2 Pin assignment
No. Signal Name Function
1 5VDC Power input
2 USBD- USB data signal -
3 USBD+ USB data signal +
4 GND Signal ground
