Installation and Operation Manual S400 series 4
To do so, it is supplied with 2 connection cables:
• 1 connector-free cable for the power supply, the bus, the NMEA IN & OUT, the alarm
output
• 1 RCA cable for connection to the sounder sensor
The Depth S400 is part of the S400 advanSea family of navigation instruments,
including instruments for measuring speed, depth, and wind. They may be connected
together to form an integrated data system for a boat (see chapter 2.6).
1.2. Components supplied with your Depth
S400
The Depth S400 comes with (as standard):
- protective cover
- user manual
- warranty card
- adhesive rear sealing joint for flush mounting
The Depth S400 does not come with sensors. You can order complete kits, or
consult our website www.advanSea.com
.
You will also find a complete list of accessories at www.advanSea.com
1.3. Technical characteristics
Measurement characteristics
Sounder:
Measurement range: from 0.5 to 199 meters
Operating frequency: 200 kHz
Accuracy: ±0.1 meter up to 5.0 meters and ≤2% beyond 5.0
meters (this accuracy is given for a constant sound speed in
water of 1490 m/s)
Resolution: 0.1 from 0 to 19.9 and 1 beyond
Configurable offset: ±9.9 meters
Battery voltage:
Measurement range: from 10.0V to 16.5V
Accuracy: ±0.2V
Resolution: 0.1V
