Advantage Controls MegaTron User Manual

11
Boiler Conductivity Electrodes
Throttling device
1/2" pipe
between probe
and throttle
device and
flush valve
Electrically
actuated
blow down
valve
Electrode within a 1"
cross with electrical
connection vented
Fully ported
gate or ball valve
1" Continuous
blow down line
Advantage
Controls, Inc.
5
4
3
2
1
SET UP
RUN
CANCEL
HELP
0
9
8
7
6
HOME
BACK
!
Warning - Do not use on bottom blowdown lines, only continuous or surface blowdown lines.
Typical Timed Sampling and Sample and Hold Boiler Installation
Throttling device
approximately 18"
past probe
Electrode within a 1"
cross with electrical
connection vented
1/2" pipe between
probe and throttle
device and to the
flush valve
Electrically actuated
blow down valve
To drain
Fully ported
gate or ball
valve
1" Continuous
blow down line
Advantage
Controls, Inc.
5
4
3
2
1
SET UP
RUN
CANCEL
HELP
0
9
8
7
6
HOME
BACK
!
Warning - Do not use on bottom blowdown lines, only continuous or surface blowdown lines.
