EKI-1351/EKI-1352/EKI-1521/1522/1524 User Manual 22
2.3 Connecting Hardward
Next, we will explain how to find a proper location for your EKI serial device server,
and then explain how to connect to the network, hook up the power cable, and con-
nect to the EKI device server serial port.
2.3.1 Choosing a Location
Due to its versatility and innovative design, EKI serial device server can be :
Fixed to a panel mount
Fixed to a DIN-rail.
2.3.1.1 Panel/Wallmounting
The EKI serial device servers can be attached to a wall using the included metal
brackets. Each bracket comes with four screws; and then you can install the device
firmly via the components, please see Figure as below.
Figure 2.13 Combining the Metal Mounting Kit
